Dk7750 High Precision Medium Speed CNC Wire Cutting Machine, Slow Speed Metal Processing

Basic Info.

Model NO.	DK7750
Numerical Control	CNC/MNC
Processing Precision	0.01~0.02(mm)
Performance Classification	Economical CNC Machine Tools
Certification	ISO 9001
Condition	New
Max Productivity(mm²/Min	≥180mm²/Min
Wrie Diameter(mm)	0.1-0.25mm
Transport Package	Standard Export Packaging
Specification	1900*1280*1800mm
Trademark	BMD
Origin	China
HS Code	8456301090
Production Capacity	150/Month

Product Description

New Condition Wire Cutting CNC EDM Medium Speed Wire Cutting Machine

Medium speed CNC EDM wire cutting machine, operation directly inputs material and the thicknessfor processing, no need further instruction from the operator. Import linear guide, ball screw. Servocontrol of Panasonic servo motor from Japan, effectively ensuring accurate position. Automatictightening system ensures constant tension of molybdenum wire. Gemstone guide wheel is durableand operation stable. Filtration core and water tank with slow filament structure, with clean filtrationand good smoothness. The medium speed multi- cutting can achieve nice surface roughness.

Machine model	DK7720	DK7735	DK7745	DK7750
Weight	800 kg	1100	1400	1800
Dimension (L*W*H)	1200*900*1300	1400*1100*1600	1600*1200*1600	2000*1500*1900
Worktable size(mm)	490*380	710*460	810*570	900*600
Travel size (mm)	200*250	400*350	450*550	630*500
Max Workpiece Thichness (mm)adjustable	200	500	500	500
Max workpiece weight(kg)	100	500	500	800
Max Productivity(mm²/min)	≥180mm²/min	≥180mm²/min	≥180mm²/min	≥180mm²/min
Best surface roughness(Ra)	Ra≤1.0μm	Ra≤1.0μm	Ra≤1.0μm	Ra≤1.0μm
Wrie diameter(mm)	0.1-0.25mm	0.1-0.25mm	0.1-0.25mm	0.1-0.25mm
Taper angle	6°/80mm-12°/80mm	6°/80mm-12°/80mm	6°/80mm-12°/80mm	6°/80mm-12°/80mm
Accuracy(mm)	≤±0.005mm	≤±0.005mm	≤±0.005mm	≤±0.005mm
Power supply	380V/50HZ	380V/51HZ	380V/51HZ	380V/50HZ

OTHER PRODUCTS

SUZHOU BAOMADE ELECTROMECHANICAL CO, LTD is located in Suzhou City, national High-tech Development Zone.The company is a professional manufacturer for electrical discharging equipment. It is mainly engaged in the researchof electrical discharging machine and special technology and relative equipment. The medium speed wire cut EDMmachine is featured in multi-cutting function, high efficiency, excellent finish surface, the effect is close to that of brasswire cutting. The high speed small hole drilling machine, fast speed EDM wire cutting and medium speed wire cuttingmachines are exported to the United States, Italy, India, Pakistan, Singapore, Egypt and other countries of the world. We can provide DK7725--DK77100, BMD400A--BMD800A and other series of products with machining efficiency upto 250mm²/min and smoothness Ra<0.8μm, which are widely used in various mold making industries. The HMD703, DB703, DD703 series of EDM hole drilling machines developed by our company are high accuracy andreliable quality. The processing aperture is φ0.2mm-φ3.0mm, and the aperture range can be expanded according tocustomers requirements. The first and second strokes of the spindle of the small hole drilling machine adopt linearguide rail, which is swift and stable.The company can provide various types of EDM machine tools, EDM250-EDM650 series products, the original electricimpulse has fast processing efficiency, good quality and high precision. The Y axis track is composed of V shape andplane structure, verticality and parallelism is stable to insure accuracy.
Our Advantages:1,We have decades of professional manufacturing experience in electric processing equipment. Our wire cuttingmachine function, high efficiency, high finish, the effect is close to that of slow wire cutting equipments.2,After years of practical processing experience, we have developed a professional database to solve theconsistency of products. The operator can only input the processing requirements. 3, We also undertake customized services. 4. Our speed is faster. Generally, people actually cut at 6000 square millimeters per hour, and we actually cutat 10000 square millimeters per hour, 5.5 amperes per hour.5.We have a special database to directly input the material thickness, cutting process, high speed standard,and high gloss novice cutting.6, Generally, HT150 is used for castings made by manufacturers, we use HT250, and HT400 is used for integratedmiddle wire, which can ensure the lasting accuracy.7. Our machine is a mechanical part with complete separation of mechanical and electrical parts, without anyelectrical appliances. Generally, there is an electrical box at the right rear of the machine tool to reduce the failure rate.8,Our steel inlaid guide rail is made of 20 chrome material, and the surface hardness is up to 53 degrees. The wearresistance is good. Generally, the manufacturer uses bearing steel for direct flame treatment. The hardness is nothigh, and the deformation accuracy cannot be guaranteed for a long time.

Q:Are you manufacturer?
A: Yes, we are manufacturer all models of CNC wire EDM cutting machine, small hole CNC drilling machine.Welcome to visit us!Q: What payment term do you accept?
A: We are flexible on payment terms, please contact us for details
Q: What information do you need before making quotation?
A: Worktable size or table travel size you required. Surface roughness and cutting speed requirements, maxworking thickness
Q: What should I do that start a new business in EDM wire cutting machine, cnc machining center area?
A: Please contact us immediately. We provide free Pre sales consultant service of CNC wire EDM cutting machines,small hole drilling machine
Q: Why choose you? What is the difference between you and other Chinese suppliers?
A: We have specialized in this area for over 10 years. Our EDM wire cutting machines, precision small hole drillingmachine are exported to India, Mexico, Turkey, Canada, Vietnam, Thailand and etc. You can get higher qualityproduct & better professional service from our company with competitive price
Q: I'm worried about after-sales service.A: Warranty is one year. Any parts damaged during warranty will be replaced for free! We provide spare partsfor life time at cost price Electrical parts such as boards and servo drives, we'll provide them for life time as well at cost price.
